BMS LFP 4S 6A (SLCT) 12.8V LiFePO₄ Battery Protection Board for 4S Battery Pack

₹89.00 (inc. GST)
You save (%)

esigned specifically for 4S (12.8V) LiFePO₄ battery packs
Supports 6A continuous and 8A peak current
Built-in overcharge protection
Integrated over-discharge protection

16 Items sold in last

Add Products worth ₹1000.00 to cart and get free shipping!

In stock

18 People watching this product now!

SKU: RY1462 Categories: Batteries BMS and Accessories, Batteries and Accessories

Description

BMS LFP 4S 6A (SLCT) – Reliable Battery Protection for 12.8V LiFePO₄ Battery Packs

The BMS LFP 4S 6A (SLCT) is a high-quality Battery Management System (BMS) engineered for 4S (4-cell) LiFePO₄ battery packs with a 12.8V nominal voltage and 14.6V maximum charging voltage. Designed to deliver 6A continuous current and up to 8A peak current, this compact protection board ensures safe charging and discharging by continuously monitoring each cell.

The integrated protection circuitry safeguards your battery pack against overcharge, over-discharge, overcurrent, and short circuits, helping extend battery life and improve overall system safety. Its ultra-slim PCB design makes it ideal for compact battery packs used in solar lighting, robotics, UPS systems, and portable electronic devices.

Whether you’re building a custom LiFePO₄ battery pack or replacing an existing BMS, this module offers dependable protection with easy installation and reliable performance.

Key Features

Designed specifically for 4S (12.8V) LiFePO₄ battery packs
Supports 6A continuous and 8A peak current
Built-in overcharge protection
Integrated over-discharge protection
Overcurrent protection with automatic recovery
Short circuit protection for enhanced safety
Compact, lightweight, and ultra-slim PCB
Clearly labeled solder pads for easy wiring
Compatible with 18650, pouch, and prismatic LiFePO₄ cells
Reliable battery protection for DIY and commercial applications

Technical Specifications

Parameter	Specification
Model	BMS LFP 4S 6A (SLCT)
Battery Chemistry	LiFePO₄ (Lithium Iron Phosphate)
Battery Configuration	4S (4 Cells in Series)
Nominal Voltage	12.8V
Maximum Charging Voltage	14.6V
Continuous Current	6A
Peak Current	Up to 8A (Short Duration)
Overcharge Protection Voltage	3.75V ± 0.05V per Cell
Over-discharge Cutoff Voltage	2.0V ± 0.05V per Cell
Overcurrent Protection	Yes (Auto Recovery)
Short Circuit Protection	Yes
Cell Balancing	Not Supported
PCB Size	Approx. 50 × 12 mm
Connection Terminals	B-, B1, B2, B3, B4, P-
Weight	Less than 6 g

Protection Functions

Overcharge Protection

Automatically disconnects charging when any cell exceeds the safe voltage limit, protecting the battery from damage.

Over-discharge Protection

Cuts off the output before the battery voltage drops below the safe operating range, increasing battery lifespan.

Overcurrent Protection

Prevents excessive current flow and automatically restores normal operation once the fault is removed.

Short Circuit Protection

Instantly disconnects the battery during short circuit conditions to protect both the battery pack and connected devices.

Applications

The BMS LFP 4S 6A (SLCT) is suitable for a variety of low-power LiFePO₄ battery applications, including:

Solar-Powered LED Lighting Systems
DIY 12.8V LiFePO₄ Battery Packs
Portable Power Banks
Fishing Lamps and Outdoor Battery Packs
Rechargeable Flashlights and Lanterns
Portable UPS Systems
Robotics Projects
IoT and Embedded Systems
Battery Backup Units
Small Electric Mobility Devices

Package Includes

1 × BMS LFP 4S 6A (SLCT) Battery Protection Board

Why Choose This BMS?

Optimized for 4S 12.8V LiFePO₄ batteries
High reliability with multiple built-in protection features
Compact PCB fits space-constrained battery enclosures
Easy installation with clearly marked solder pads
Improves battery safety, performance, and service life
Suitable for DIY enthusiasts, engineers, manufacturers, and repair professionals
