KY-035 Hall Magnetic Sensor Module

(1 customer review)

Original price was: ₹39.00.Current price is: ₹29.00. (inc. GST)

In stock

  • Cash on Delivery(COD) available on orders above 499/-
  • Free shipping on prepaid orders above 499/- use FREESHIP Coupon code!
  • 10 Days Return Policy!
  • Dispatch in 24 Hours from Warehouse!
Add to Wishlist
Add to Wishlist
  1. Supply Voltage(Vcc) – 5 V
  2. Output Current (IO) – 10 mA
  3. Operating Temperature – 40 to 100 Degree Celcius
  4. Can detect both the magnetic poles
SKU: RY1009 Categories: , ,

Description

KY-035 is a hall magnetic sensor module that houses an AH49E linear hall effect device that is operated with a help of a magnetic source. The module varies the output voltage, which is generally set by the input supply voltage and varies in proportion to the strength of the magnetic field around the sensor.

Pin Configuration of KY-035

Below is the pin configuration of the KY-035 magnetic sensor. This pin configuration can be used when connecting the module to any microcontroller.

Pin NumberPin Type
1Signal(Analog)
2Vcc(+5V)
3Ground



Features of KY-035

Here are some basic features and specifications of the magnetic sensor.

  1. Supply Voltage(Vcc) – 5 V
  2. Output Current (IO) – 10 mA
  3. Operating Temperature – 40 to 100 Degree Celcius
  4. Can detect both the magnetic poles

Applications of KY-035

Here are some of the application where KY-035 magnetic sensor come into use:

  1. Motor control
  2. Metal detector
  3. Position sensing
  4. Magnetic Code Reading
  5. Current sensing
